small jaw crusher for sale
Table of Contents
What is a Small Jaw Crusher?
A small jaw crusher is a compact, mechanically simple crushing machine designed to reduce the size of hard rocks, ores, and other solid materials. It operates using a fixed and a movable jaw plate, creating a V-shaped cavity where materials are crushed into smaller pieces through compressive force. Its small footprint, low cost, and ease of op
Primary Applications and Processable Materials
Small jaw crushers are versatile and widely used in:
Primary Crushing: The first stage in reducing large rocks.
Laboratory & Pilot Plants: For sample preparation and testing.
Recycling: Crushing concrete, bricks, and construction waste.
Small-scale Mining & Rock Quarrying: Ideal for low-volume production.
Agriculture: Processing minerals for soil amendment.
Materials it can crush: Granite, basalt, quartz, iron ore, concrete, construction debris, limestone, and various minerals.
Example Application in Gold Mining
In gold mining, small jaw crushers are crucial for processing ore samples and running small-scale operations. For instance, a prospector or a small mining cooperative can use a portable small jaw crusher directly at the site to crush gold-bearing quartz veins. The crushed material is then further processed through a hammer mill or directly fed into a sluice box or gold centrifugal concentrator for gold extraction. This on-site primary crushing increases efficiency by reducing transport costs and enabling immediate processing of ore.
Small Jaw Crusher Models & Specifications
Here are some popular models we offer:
| Model | Feed Opening | Max. Feed Size (mm) | Discharge Opening Range (mm) | Capacity (t/h) | Power (kW) |
|---|---|---|---|---|---|
| JC-60 | 150×125 | 80 | 10-40 | 1-3 | 5.5 |
| JC-90 | 225×165 | 120 | 20-60 | 3-8 | 11 |
| JC-150 | 350×250 | 210 | 25-60 | 8-16 | 18.5 |
| JC-250 | 400×600 | 340 | 40-100 | 16-30 | 30 |
Note: Specifications may vary slightly. Contact us for detailed datasheets.
Global Supply & Our Product Advantages
We provide high-quality small jaw crushers for sale to global customers, supported by reliable shipping and local service networks.
Our Key Features and Advantages:
Robust Construction: High-grade steel frame and jaw plates for durability.
High Crushing Efficiency: Optimized cavity design for greater output and well-graded product.
Easy Maintenance & Adjustment: Simple design allows easy replacement of wear parts and adjustment of discharge size.
Energy Efficient: Low power consumption reduces operational costs.
Versatility: Suitable for both stationary and mobile mounting.
Customization Options: Available with electric or diesel engines, and different guarding options.
How to Choose the Right Small Jaw Crusher for Sale
Consider these factors when making your selection:
Feed Material & Hardness: Determine the type and maximum size of the rock you need to crush.
Required Output Size & Capacity: Match the crusher’s discharge adjustment range and hourly capacity (t/h) with your production goals.
Power Source: Choose between electric motor (for sites with grid power) or diesel engine (for remote or mobile sites)
Mobility Needs: Decide if you need a stationary unit, a skid-mounted version, or one integrated into a portable plant.
After-Sales Service: Ensure the supplier can provide timely spare parts and technical support.
Other Considerations
Beyond the crusher itself, consider peripheral equipment like a pre-screening grizzly to remove fines, a feeding hopper, and a discharge conveyor for a complete system. Regular maintenance, such as lubricating bearings and timely jaw plate rotation/replacement, is key to maximizing service life and performance.
Request for Quotation (RFQ)
Are you interested in our small jaw crushers? Please provide the details below for a precise quotation and technical recommendation:
Material to be crushed:
Maximum feed size:
Required output size:
Desired capacity (tons per hour):
Preferred power source (Electric/Diesel):
Intended application:
Delivery destination:
Contact us today to get the best small jaw crusher for your specific needs and unlock greater productivity!
